Multi-Dimensional Circuit Carriers Using Additive Manufacturing

Prototypes for New Printed Circuit Boards (PCBs) Created With EOS Technology

At the beginning of 2016, many people were writing about the end of Moore's Law, anticipating that the performance of computer chips would no longer be doubling every two years. The reason for this is that the structures on the processors themselves are already within a few nanometers of what is possible. Further reductions are almost impossible from a technical point of view. In order to continue improving performance, manufacturers are working on the architecture, which stacks multiple structural layers on top of one another. A similar approach has already been established within the field of circuit carriers. The German firm of Beta LAYOUT GmbH has successfully harnessed EOS technology to manufacture and test the prototypes for these innovative carriers.

"Thanks to its many advantages, additive manufacturing technology offers high added value for a broad range of market participants. Research and development profits through our services, which, in turn, has a positive impact on our business model. This enables us to offer the benefits of advanced technology to a large number of users."
Manuel Martin | Product Manager 3D-MID | Beta LAYOUT GmbH

Challenge

Production of individual prototypes for circuit carriers

Circuit carriers and traditional PCBs have always been a little overshadowed by the microprocessors that operate on them. This is somewhat unjust because, of course, having the best brain is of little use without the benefits of a high-performance central nervous system. It's a similar story in the microelectronics sector: almost all contemporary devices require a circuit board in order to incorporate one or more chips, plus the additionally required electrical components. This creates a network that fulfills a range of tasks, from supplying of electricity, circuitry, through to the output of signals.

In new devices, there is often only a very small amount of installation space available for conventional circuit boards. One reason for this is that a lot of electronic equipment is becoming ever smaller; and even when the form itself is larger, there tends to be very little space left over for the actual electronics. The existing volume is required for housing screens, for example, more and more interfaces and output points, as well as larger batteries. The time when a simple lab PCB was sufficient for the experimental construction of new circuitry are now, in most cases and most sectors, long gone. Alongside the available installation space, weight is a key factor – compact, three-dimensionally constructed circuit boards also have an important role to play here.

With contemporary electronic products, the circuitry often has to compete for the limited space within the housing. When conventionally stacked, PCBs can no longer accommodate all of the necessary components, so that the aforementioned three-dimensional circuit carriers become the solution of choice. Here again, the ever-shorter life cycles of many devices pose additional challenges: injection molding is far too expensive to manufacture prototypes. For this reason, Beta LAYOUT GmbH decided to search for a cheaper, high-performance alternative.
